West Penn AQ226 Aquaseal 14 AWG 2 Conductor Unshielded Speaker Wire (Black, By the Foot)

14/2 Unshielded Indoor/Outdoor Direct Burial CL3/FPL Rated Audio, Control, Alarm Direct Burial Cable with Aquaseal Water Blocking Tape - Black - Sold by the Foot

14/2 Stranded bare copper conductors, overall unshielded with Aquaseal tape and overall jacket.

APPLICATION: Materials suitable for outdoor use (direct burial), and indoor trays, allows a variety of uses for (Low voltage industrial process control circuits, Power-Limited circuits, Power-Limited fire alarm circuits, Power-Limited tray cable PLTC).

Specifications:

• CONSTRUCTION & DIMENSIONS
• CONDUCTOR PARAMETER
• Number of Conductors: 2
• AWG Size: 14
• Conductor Stranding: 19x27
• Conductor Type: Bare copper
• Nominal DCR: 2.7 Ohm/1000ft
• INSULATION PARAMETER
• Insulation Type: PVC-Nylon
• Insulation Thickness: 0.02 in
• Insulation Color Code: 1. Black 2. Red
• SHIELDING PARAMETER
• Shield Type: Aquaseal Water Blocking Tape
• ELECTRICAL CHARACTERISTICS
• Nom. Cap. Between Conductors: 32 pF/ft
• OVERALL CONSTRUCTION PARAMETERS
• Jacket Type: UV Resistant PVC
• Jacket Thickness: 0.04 in
• Nominal Cable O.D.: 0.31 in
• Plenum: No
• NEC UL Rating: CL3, FPL, PLTC
• RoHS Compliant: Yes
• TIA Test: TIA455-82 Water Penetration Test
• Pull Tension: 84 lbs
• Bend Radius: 2.79 in
• Cable Weight: 59 lbs
