Key Features
- In-Line Active DI for Instruments
- Ultra-Hi-Z, Lockable 1/4" Input
- XLR 3-Pin Output
- Class-A Output Buffer and Amplifier
- Switchable 15 or 30 dB Input Pad
- 3-Way Ground-Lift Switch
- Runs off 48V Phantom Power
- Durable, All-Metal Housing
Description
Active Mono Direct Box with -15dB and -30dB Pads, and Ground Lift Switch
A BEAST OF A DI
The DM3 is an active, inline DI with Ultra-HiZ input and an impressively compact design - in many ways, the DM3 will prove to be your key to great sound!
RECOMMENDED USE
Electric guitar, bass guitar, piezo pickups, keyboard, synthesizers, drum machines, laptops
Features:
- Ultra-HiZ input for getting the best out of your instrument
- Massive headroom for even the hottest instruments
- A new standard to the ground lift switch
- Lockable 1/4" input jack to prevent accidental disconnects
- Dedicated Class-A output buffer amplifier and premium finish
- Slim, all-metal discrete housing and gold XLR connectors
Specifications:
- Power
- Electrical Impedance: 86 Ohms
- Recommended Load Impedance: >1K Ohms
- Connectivity
- Input: 6.3 mm (1/4 in.) TRS jack
- Output: 3-pin male XLR connector
- Powering: 48V Phantom Power (P48 according to IEC 61938)
- Sound
- Frequency range: 10 Hz - 120 kHz (-0.3 dB)
- Current consumption: 3.8 mA
- Max input level (0.5% THD): 19 / 34 / 49 dBV (9.0 / 51 / 285 V)
- Output noise level: 1 μV
- Dimensions
- DI diameter: 20 mm (0.79 in.)
- DI length: 95.5 mm (3.76 in.)
- DI weight: 70 g (2.47 oz.)
What's in the box
- DM3
- Screwdriver
- sE 1/4" plug keychain
- sE Logo Sticker
- User manual with warranty card
Details
- Manufacturer: sE Electronics
- MPN: DM3-DI-U
- Model Number: DM3
- UPC: 819032011362
