Tascam US-4x4HR USB-C Audio/MIDI Interface

4-in/4-out USB-C Audio Interface with 4 x XLR Inputs, 4 x 1/4" Inputs, MIDI, and Software Bundle - Mac/PC/iOS

4-IN/4-OUT High-Resolution USB Audio/MIDI Interface

4 XLR mic inputs and 4 TRS line inputs (IN 1-2 guitar input support) audio interface with implemented MIDI IN/OUT ports. Equipped loopback function and OBS support makes this interface an excellent choice for podcasts and live streaming. The new US-4x4HR offers simple and intuitive operation, sophisticated looks, a rich assortment of software bundles, and improved audio performance with 192 kHz support, thanks to the newly enhanced audio circuit.

Features

• 4-in/4-out USB audio interface
• Supports up to 24-bit/ 192kHz audio formats
• Improved TASCAM driver with selectable buffer size from 4 samples provides low-latency and stability (Windows: TASCAM native driver)
• 4 XLR/TRS combo inputs equipped with Ultra HDDA mic preamps and +48V phantom power
• Combo TRS line inputs with guitar input support on IN1-2
• TRS line outputs 1-2/3-4
• Two headphone outputs
• Equipped with MIDI IN/OUT terminals

Specs

• Sampling Frequency : 44.1k/48k/88.2k/96k/176.4k/192k Hz
• Mic amp EIN (equivalent input noise) : -128dBu or lower
• THD + N : 0.0013% (MIC IN, 1kHz sine wave, -5dBFS input, GAIN knob at minimum, 20kHz SPCL LPF)
• S/N ratio : 110dB (MIC IN, GAIN knob at minimum, 20kHz SPCL LPF+A-Weight)
• Power consumption : 2.25W
• Dimensions : 296(W) x 65(H) x 160(D)mm (including protrusions)
• Weight : 1.6kg

What's in the box

• US-4x4HR
• AC adapter PS-P1220E
• USB cable (Type-A to Type-C)
• DAW software installation guide
• DAW plug-in software installation guide set
• Owner's manual（warranty card included)
