Key Features
- 35 Watts Per Channel
- 1/4" and RCA Inputs
- Spring-Loaded Terminal Outputs
- Fault & Thermal Protection
- Front Panel Heat Sinking
- Made in the USA
Description
Stereo Power Amp, 35 Watts per Channel at 8 Ohms, 1/4" and RCA Inputs
The RA235 is a virtually indestructible single rack space amplifier intended for musicians and studio owners alike. The unit is ideal for home studio applications or wherever a clean, efficient, medium wattage amp is required.
Features:
- 35 Watts per channel of clean amplification.
- 1/4" and RCA inputs.
- Convenient spring-loaded output terminals.
- Front panel heat sinking for proper venting.
- Protected output stage.
Specifications:
- Recommended Load: 8 Ohms
- Frequency Response: 5 Hz - 40 kHz
- Equiv. Input Noise: 100 mV typical, A Weighted, 600 Ohms
- S/N Ratio: 114 dB @ 35 Watts
- Gain: 34 dB
- Input Impedance: 47 K Ohms
- Power: 120 VAC 50-60 Hz
- Size: 19" x 1.75" x 5" (48 x 4.5 x 12.7 cm)
- Weight: 5.5 lbs (2.5 kg)
Details
- Manufacturer: Rolls
- MPN: RA235
- Model Number: RA235
- UPC: 675889023503
