Key Features
- Male 3-Pin XLR Connector
- Industry Standard
- Solder Cups
- Nickel Metal Housing
- Silver Contacts
Description
Male 3-Pin XLR Cable End Connector, XX Series, Nickel Housing, Silver Contacts
The Neutrik NC3MXX is a rugged and heavy-duty male 3-pin XLR solder cable connector with nickel metal housing and silver contacts. The NC3MXX is part of Neutrik's next generation XX Series of XLR cable connectors. The NC3MXX features easy assembly, a newly improved chuck type strain relief and is suitable for both analog and digital applications.
Color coding and easy identification is readily available with a full range of colored rings and boots. The color coded rings can even be swapped out after assembly is complete.
Neutrik XX-Series XLR Cable Connectors
The XX-Series is the next generation of the globally accepted standard of XLR cable connectors. The successor of the X series offers several new features that make it more reliable. The cable connectors are easier to assemble, the contacts are even more robust and the strain relief system has been improved.
Features:
- Male connector with improved locking recess without "window", more stringent housing increases durability
- Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster
- Boot with polyurethane gland gives high protection to cable bending stresses
- Colored rings and boots available for coding or identification
- Sleek and ergonomic design - valuable and handy
- Rugged zinc diecast shell, longlasting and dependable
- Internal thread on shell is well proteced against any damage
- Branded with unique hologram - guarantees genuine and authentic Neutrik product
Specifications:
- Product
- Title: NC3MXX
- Connection Type: XLR
- Gender: male
- Electrical
- Capacitance between contacts: <= 4 pF
- Contact resistance: <= 3 mΩ (inner)
- Dielectric strength: 1,5 kVdc
- Insulation resistance: > 10 GΩ (initial)
- Rated current per contact: 16 A
- Rated voltage: 50 V
- Mechanical
- Cable O.D.: 3.5 - 8.0 mm
- Insertion force: <= 20 N
- Withdrawal force: <= 20 N
- Lifetime: > 1000 mating cycles
- Wiresize: max. 2.5 mm²
- Wiresize: max. 14 AWG
- Wiring: Solder contacts
- Locking device: Latch lock
- Material
- Boot: Polyurethan
- Contact plating: 2 µm Ag
- Contacts: Brass (CuZn39Pb3)
- Insert: Polyamide (PA 6.6 30 % GR)
- Locking element: Zinc diecast (ZnAl4Cu1)
- Shell: Zinc diecast (ZnAl4Cu1)
- Shell plating: Nickel
- Strain relief: Polyacetal (POM)
- Environmental
- Flammability: UL 94 HB
- Standard compliance: IEC 61076-2-103
- Protection class: IP 40
- Solderability: Complies with IEC 68-2-20
- Temperature range: -30 °C to +80 °C
