Key Features
- 2 x Stereo TRS Inputs
- 4-Channels, Each with Volume Control
- 1/8" & 1/4" Headphone Output Per Channel
- Selector Switch for Each Output 1-2
- Rugged Metal Construction
Description
4-Channel Headphone Amplifier
THE IDEAL COMPACT HEADPHONE AMP For small and medium studio applications
The HP4E professional headphone amplifier features two stereo input and four stereo output channels of high-quality audio. Designed for ease of use, convenient switches on the front plate enable you to select your designed input. Each channel features both a 1/8" (3.5 mm) and 1/4" (6.3 mm) headphone output for easy connectivity - no adapters required. Housed in a sturdy metal chassis, the HP4E is an ideal headphone amp for any recording session.
Features:
- Small footprint with 4 totally independent stereo high-power amplifiers in half 1 RU package
- Carefully selected components for high quality audio even at extremely high volume levels
- Two stereo inputs for full flexibility with independent selection of input for each output
- Two outputs per channel with each a 1/4" (6.3mm) and 1/8" (3.5mm) stereo socket so no adapter is needed
- Rugged construction with strong metal housing to withstand rough working environments
Specifications:
- Design: 4-Channel Headphone Amplifier
- Input: 6.3 mm (1/4") socket - unbalanced
- Input impedance: 100k Ohms
- Output: 3.5 mm (1/8") socket and 6.3 mm (1/4") socket per channel
- Output impedance: 11 Ohms
- Audio frequency bandwidth: 20 to 20000 Hz
- Max. output level: 220 mW
- Distortion: <0.05%
- Signal to Noise: better than 85 dB-A
- Net weight (incl. power supply): 760 g
Details
- Manufacturer: AKG
- MPN: 3450H00010
- Model Number: HP4E
- UPC: 885038038825
